High Precision 100W 200W 300W Fiber Laser Welding Machine Mini Laser Welder for Jewelry Gold and Silver Weld

Output Power : 200W

Usage : welding

Place of Origin : China

condition : New

Key Selling Points : Easy To Operate

warranty : 3 years

Weight : 110

Product name : Laser Welding Machine

Laser power : 200W

Application : Jewelry Welding Products

MOQ : 1

Price : $1,200

Contact Now

Specification

Model	SM-200-YAG
Laser source type	Fiber source
Laser Out Power	200W
Laser wavelength	1070nm
Laser Source	YAG
Focal spot diameter	0.1-3mm
Laser frequency	1-50Hz
Repeatability	±0.01mm
Machine operating temperature	0~40℃
Electricity demand	220V
Cooling method	Water Chiller Hanli
Continuous operating time	24 hours
Weight	200kg
Dimensions	10805901230mm

Features:

High speed, high efficiency, deep, small deformation, small heat effect area, high welding quality, pollution free welding spot.Jewelry laser welder is mainly used in perforating and spot welding of white gold, platinum, carbon steel. The spot welding process is thermal conduction, i.e. the laser radiation heats the surface of work piece, and the surface heat diffuses to the interior through thermal conduction and melts the work piece by controlling the width, energy, peak power and repeating frequency of laser pulse to form specific molten pool.

1. Ceramic converging cavity is imported from UK. Good performance of corrosion resistant and high temperature resistant. The life of xenon lamp is: Max 5 million times.
2. Able to work for 24 hours continuously, stable performance; Human-based design accords with ergonomics, avoiding fatigue after long time working.
3. Widely used in jewelry accessories, electronic components, glasses clocks and watches, hardware, precision equipment, medical equipment, auto parts, gifts and crafts, etc.

Standard accessories:
1. Laser power supply, 1 set
2. Laser crystal rod, 1set
3. Focus mirror & Beam expander, 1 set
4. Ceramic converging cavity, 1set
5. Microscope x10, 1set
6. Xenon lamp, 1set
7. Protective lens, 1set
8. Cooling system, 1set
9. Foot switch, 1 set

High Precision 100W 200W 300W Fiber Laser Welding Machine Mini Laser Welder for Jewelry Gold and Silver Weld Images
