MAX MFSC-1000X MFSC-1000C Single Module Fiber Laser Source MAX 1000W Laser Source for Laser Cutting Welding Machine

Product Categories
Please input your companyname!
Contact Now

MAX MFSC-1000X MFSC-1000C Single Module Fiber Laser Source MAX 1000W Laser Source for Laser Cutting Welding Machine

spare parts type : Laser Source

Brand Name : LEISHEN

Place of Origin : Hubei, China

condition : Used

key selling points : Competitive Price

warranty : 6 Month

weight (kg) : 60

Weight (KG) : 20 KG

Product name : Raycus Fiber Laser Source

Applicable Industries : Machinery Repair Shops

Key Selling Points : Low Maintenance Cost

MOQ : 1

Price : $1,399

Contact Now

Product Parameters
Models MFSC-1500X
OPTICAL SPECIFICATIONS
Nominal Power 1500W
Mode of Operation CW/Modulated
Polarization Random
Power Tunability 10 to 100%
Wavelength 1080 ± 10 nm
Power Stability ±1 %
Laser Beam Quality, BPP ≤1.5 mm x mrad (50μm QBH)
Modulation Frequency ≤20 kHz
Preview Red Light Power 150 μW
FIBER DELIVERY SYSTEM
Interface QBH (LOC)
Length 15m standard, other lengths optional
Diameter 50 μm
Bending Radius 200 mm
ELECTRICAL RATINGS
Supply Voltage 220VAC (-15% to +10%) Single-phase
OTHER SPECIFICATIONS
Operating Temperature +10 to +40℃
Storage Temperature -10 to +60℃
Humidity 10 to 85%
Cooling Method Water Cooling
Cooling Medium Distilled water/ Glycol Antifreeze
Dimension 482.6×800×193mm (W×D×H)
Weight 53(±3) kg
